3x Intake Valve Kit for Yamaha 5KM-12111-00-00 3YF-12113-00-00 5H0-12119-00-00

Spread the love
Share on facebook
Share on twitter
Share on linkedin
Share on whatsapp
Share on telegram
Share on tumblr
Share on pinterest

Premium Quality Replacement Part
3x Intake Valve Kit for Yamaha 5KM-12111-00-00 3YF-12113-00-00 5H0-12119-00-00
For Yamaha Models:
Grizzly 660 4×4 2002-2008
Rhino 660 4×4 2004-2007
Order Includes:
3 x Intake Valve: 5KM-12111-00-00 3YF-12111-00-00
Intake Valve Length: 1.18″ | 30.0 mm
Intake Valve Diameter: 3.95″ | 100.5 mm
3 x Inner Valve Spring: 3YF-12113-00-00
Width: 0.97″ | 23.8 mm
Height: 1.31″ | 33.3 mm
Thickness: 0.11″ | 3.0 mm
3 x Valve Stem Seal: 5H0-12119-00-00
Length: 0.47″ | 12.0 mm
Width: 0.35″ | 9.0 mm
Inner Diameter: 0.18″ | 4.7 mm
Outer Diameter: 0.37″ | 9.4 mm
6 x Valve Cotter: 4G0-12118-00-00
Width: 0.14 ” | 3.8 mm
Length: 0.33 ” | 8.5 mm
Height: 0.23 ” | 6.0 mm
**
