Kawasaki Mule Water Pump Impeller, Mechanical Seal & Oil Seal Kit
Fits the Following Kawasaki Mule ATV Models:Kawasaki Mule 2500 KAF620 1994-2000Kawasaki Mule 2510 KAF620 1994-2000Kawasaki Mule 2520 Turf KAF620 1995-2000Kawasaki Mule 3000 KAF620 2001-2008Kawasaki Mule 3020 Turf KAF620 2001-2003Kawasaki Mule 3010 KAF620 2001-2008Kawasaki Mule 3010 Advantage Classic KAF620 2003Kawasaki Mule 3010 Hardwoods Green HD KAF620 2004-2008Kawasaki Mule 4000 KAF620 2009-2016Kawasaki Mule 4010 SE 2016Kawasaki Mule 4010 KAF620 2009-2016Kawasaki Mule 4010 Hardwoods Green HD KAF620 2009Kawasaki Mule 4010 RealTree APG HD KAF620 2010-2012
All Parts Replace Kawasaki OEM Parts
1x Water Pump Impeller
Kawasaki OEM |
49044-2066
1x Water Pump Mechanical Seal
Kawasaki OEM |
49063-0002, 49063-1054, 49063-1056, 49063-2056
Dimensions | 22.5mm x 17mm x 29mm
1x Water Pump Oil Seal
Kawasaki OEM |
92049-2111
Dimensions |
5mm x 10mm x 20mm
1x Water Pump Cover Gasket
Kawasaki OEM |
11060-2451
1x Water Pump Case Gasket
Kawasaki OEM |
11060-2289
1x Water Pump O-Ring
Kawasaki OEM |
670B1507
Dimensions |
10mm x 2mm x 7mm
**
