Carburetor for Honda 16100-KA6-004 16100-KA6-014 16100-KA6-024 1978-1981

Carburetor for Honda 16100-KA6-004 16100-KA6-014 16100-KA6-024 1978-1981 - Image 2

Carburetor for Honda 16100-KA6-004 16100-KA6-014 16100-KA6-024 1978-1981

SKU HYQ.11127 16100-KA6-004, 16100-KA6-014, 16100-KA6-024MPN16100-428-671, 16100-428-771 Category ATV Carburetor Tag carburetor

Premium Quality Replacement Part
Honda 4-Stroke Carburetor
For Honda Motorcycle Models:XL 250S 1978-1981Order Includes:
1x Carburetor
Replaces OEM:
16100-KA6-00416100-KA6-01416100-KA6-02416100-428-67116100-428-771
Specs & Dimensions:
Mount Type:
Spigot
Main Jet:
102
Pilot Jet
: 42
Spigot Side Bore ID:
29mm
Spigot Side Clamp OD:
40mm
Air Filter Side Bore ID:
42mm
Air Filter Side Clamp OD:
45.5mm
Slide Type:
Round Slide
Choke Type:
Butterfly
