Product: Carburetor For Kohler SV470 15HP 11.2 kW 2085333-S 1.14 Jet 26mm Bore

Premium Quality Replacement Part
Carburetor For Kohler SV470 15HP 11.2 kW 2085333-S 1.14 Jet 26mm BoreFor Kohler Models:SV470-0103 ARIENS 15 HP 11.2 kW
SV470-0108 EXCEL HUSTLER 15 HP 11.2 kW
SV470-0111 CUB CADET 15 HP 11.2 kW
SV470-0115 BASIC 15 HP 11.2 kW
SV470-0116 CUB CADET 15 HP 11.2 kW
SV470-0117 AL-KO 15 HP 11.2 kW
SV470-0120 EXCEL HUSTLER 15 HP 11.2 kW
SV470-0121 HOP 15 HP 11.2 kW
SV470-0122 MTD 15 HP 11.2 kW
SV470-0123 HUSQVARNA 15 HP 11.2 kW
SV470-620 ONE PAGE MODEL COMPOSITE
Order Includes:
1x Carburetor : 2085333-S 2085314-S 2085342-S 2085316-S
Bore : 26mm
Height : 106.62mm
Choke Style : Butterfly Valve
Throttle Style : Butterfly Valve
Carb Attachment Style : Flange
Air Flange Diameter : 26mm
Engine Flange Diameter : 32mm
Replace Brand : Tillotson
Jet Size : 1.14
**
