Product: Clutch Basket and Friction Plates Kit for Kawasaki Bayou 300 KLF300-A/B 1986-04

Product categories

Clutch Basket and Friction Plates Kit for Kawasaki Bayou 300 KLF300-A/B 1986-04 - Image 2

Clutch Basket and Friction Plates Kit for Kawasaki Bayou 300 KLF300-A/B 1986-04 - Image 3

Clutch Basket and Friction Plates Kit for Kawasaki Bayou 300 KLF300-A/B 1986-04

SKU LHQPJ.06093 Category ATV Clutches Tag clutch parts

Premium Quality Replacement Part
PRIMARY CLUTCH BASKETCLUTCH FRICTION PLATESCLUTCH STEEL PLATESCLUTCH SPRINGS
CLUTCH GASKET KIT
For KAWASAKI Models:Bayou 300 KLF300-A 1986-1987Bayou 300 KLF300-B 1988-2004
Part Number:
Clutch Basket
13095-1133, 13095-1364
Clutch Friction Plates
13088-041, 13088-1091
Clutch Steel Plates
13089-1005
Clutch Spring
92081-1848
Gasket
11009-1518, 11060-1225, 11060-1655
Dimensions & Measurements:
Gear Outer Diameter : 158mm | 6.22″Basket Inner Diameter : 25mm | 0.98″Basket WIdth : 63mm | 2.48″Basket Inner Diameter : 141mm | 5.55″Basket Outer Diameter : 151mm | 5.94″Clutch Friction Plate Thickness : 3mmClutch Steel Plate Thickness : 1.9mm
Order Includes:
1x Clutch Basket5x Clutch friction Plates4x Clutch Steel Plates4x Clutch Springs1x Clutch Cover Gasket
**
