Product

PremiumQuality Replacement Part
Clutch Friction and Steel Plates Kit
For Kawasaki Models:
KLX150L 2014-2018KLX150B 2017-2018
Order Includes:
1 x Clutch Friction Plate: | 13088-1077 / ID=100Clutch Friction Plate Thickness: 2.74 mm | 0.14″
Clutch Friction Plate Inner Diameter: 100.2 mm | 3.94″
Clutch Friction Plate Outer Diameter: 109.6 mm | 4.31″
3 x Clutch Friction Plate: | 13088-0040Clutch Friction Plate Thickness: 2.9 mm | 0.11″
Clutch Friction Plate Inner Diameter: 122.8 mm | 4.83″
Clutch Friction Plate Outer Diameter: 157.9 mm | 6.2″
1 x Clutch Friction Plate: | 13088-0041Clutch Friction Plate Thickness: 3.20 mm | 0.12″
Clutch Friction Plate Inner Diameter: 91 mm | 3.58″
Clutch Friction Plate Outer Diameter: 118.8 mm | 4.67″
4 x Clutch Steel Plate: | 13089-1108Clutch Friction Plate Thickness: 1.5 mm | 0.05″
Clutch Friction Plate Inner Diameter: 90 mm | 3.54″
Clutch Friction Plate Outer Diameter: 109.8 mm | 4.32″
**
