Product: Clutch Friction Steel Plates Spring and Gasket Kit for Suzuki RM-Z250 2011-2018

Premium Quality Replacement Part
CLUTCH FRICTION and STEEL PLATES
SPRINGS and GASKET KIT
Compatible with Following SUZUKI Models:RM-Z250 2011-2018
Part number:
Clutch Friction Plates
21441-40F10
Clutch Steel Plates
21451-10H0021452-10H00
Clutch Springs
21413-49H00
Clutch Gasket
11484-10H00
Dimensions & MeasurementsClutch Friction Plate Thickness: 3mm | 0.11″Clutch Friction Plate Inner Diameter: 111mm | 4.37″Clutch Friction Plate Outer Diameter: 144mm | 5.67″Clutch Steel Plate Thickness: 1.6mm | 0.06″Clutch Steel Plate Inner Diameter: 103mm | 4.07″Clutch Steel Plate Outer Diameter: 133mm | 5.23″Clutch Spring Length: 52mm | 2.04″Clutch Spring Width: 18.4mm | 0.72″
Order Includes:8x Clutch Friction Plates7x Clutch Steel Plates5x Clutch Springs1x Gasket
**
