CV Axles For Can-Am Maverick Max 1000R 2018 Rear And Front

SKU Z.15811 705502415, 705401235, 705401873, 705401236, 705401874 Category Tags ,
Spread the love
Share on facebook
Share on twitter
Share on linkedin
Share on whatsapp
Share on telegram
Share on tumblr
Share on pinterest

Premium Quality Replacement Part
Rear And Front CV AxlesFor Can-Am Models:Maverick Max 1000R 2018Order Includes:2x Rear Left Or Right CV Axles : 705502415
Length : 704 mm | 27.7 ”
Spline A Length : 27.5 mm | 1.0 ”
Spline A Boot Width : 87.3 mm | 3.4 ”
Spline A – 26 Tooth
Spline B Length : 28 mm | 1.1 ”
Spline B Boot Width : 89 mm | 3.5 ”
Spline B – 28 Tooth
1x Front Left CV Axle : 705401235, 705401873Length : 749 mm | 29.4 ”
Spline A Length : 28.5 mm | 1.1 ”
Spline A – 26 Tooth
Spline B Length : 25.4 mm | 1.0 ”
Spline B – 21 Tooth
1x Front Right CV Axle : 705401236, 705401874Length : 787.5 mm | 31 ”
Spline A Length : 28.5 mm | 1.22 ”
Spline A – 26 Tooth
Spline B Length : 60 mm | 2.36 ”
Spline B – 21 Tooth
**
