Honda XL600R Top End Engine Gasket Set
This is all the gaskets you’ll need to rebuild the top-end plus the clutch and stator for your 1983, 1984, 1985, 1986, 1987 Honda XL600R dirt bike.
Order Includes:
1x Cylinder Head Gasket
1x Cylinder Base Gasket
1x Clutch Side Crankcase Cover Gasket
1x Stator Side Crankcase Cover Gasket
2x Exhaust Header Gaskets
1x Muffler/Baffle Connector Gasket
Fits the Following Honda Motorcycles:
1983-1987 Honda XL600R
Replaces Honda OEM:
Head Gasket: 12251-MG2-792 | 12251-MG2-004 | 12251-MG2-791
Base Gasket: 12191-MN1-701 | 12191-MG3-000 | 12191-MK2-000 | 12191-MN1-670 | 12191-MN1-700
Clutch Side Crankcase Cover Gasket: 11394-MY2-623 | 11394-MY2-621 | 11394-MG3-000 | 11394-MG3-010 | 11394-MG3-307 | 11394-MK2-000
Stator Side Crankcase Cover Gasket: 11395-MN1-700 | 11395-MK2-000 | 11395-MG2-010 | 11395-MG2-000
Exhaust Header Gaskets: 18291-MN5-650 | 18291-216-000 | 18291-306-000 | 18291-KE5-000 | 18291-MN9-000
Muffler/Baffle Connector Gasket: 18391-429-010
