Product

Premium Quality Replacement Part
Exhaust Valve Kit for Yamaha Grizzly 700 YFM700 4×4 2008-2015 2019 2020-2022
For Yamaha Models:
Grizzly 700 YFM700 4×4 2008-2015 2019-2022
Order Includes:
1 x Exhaust Valve: 5VK-12121-00-00
Exhaust Valve Length: 1.25″ | 32.0 mm
Exhaust Valve Diameter: 3.77″ | 96.0 mm
1 x Inner Valve Spring: 5VK-12113-00-00
Width: 0.98″ | 25.0 mm
Height: 1.61″ | 41.1 mm
Thickness: 0.14″ | 3.6 mm
1 x Valve Stem Seal: 5H0-12119-00-00
Length: 0.47″ | 12.0 mm
Width: 0.35″ | 9.0 mm
Inner Diameter: 0.18″ | 4.7 mm
Outer Diameter: 0.37″ | 9.4 mm
2 x Valve Cotter: 4G0-12118-00-00
Width: 0.14 ” | 3.8 mm
Length: 0.33 ” | 8.5 mm
Height: 0.23 ” | 6.0 mm
**
