Product

Premium Quality Replacement Part
Front Brake Caliper Kit For Yamaha Models:Wolverine R-Spec 700 YXE700 Hunter EPS 2016-2018
Wolverine R-Spec 700 YXE700 4×4 FI EPS Special 2016
Order Includes:
1x Front Left Brake Caliper : 1XD-2580T-00-00
Height : 90.4 mm | 3.55 ”
Length : 143.1 mm | 5.63 ”
Mounting Hole Space : 116.3 mm | 4.57 ”
1x Front Right Brake Caliper : 1XD-2580U-00-00
Height : 90.6 mm | 3.56 ”
Length : 141.5 mm | 5.57 ”
Mounting Hole Space : 114.8 mm | 4.51 ”
2x Brake Disc Rotor : 1XD-F582T-00-00
Inner Diameter : 102 mm | 4.0 ”
Outer Diameter : 206 mm | 8.12 ”
Mounting Hole Space : 115.5 mm | 4.54 ”
Width : 4.1 mm | 0.16 ”
8x Disc Bolts : 90109-08087-00, 90109-08021-00, 90109-08082-00, 90109-08101-00, 90149-08268-00
Height : 19.5 mm | 0.76 ”
Length : 7.8 mm | 0.30 ”
**
