The shape of the disc ensures good heat dissipation under heavy braking sessions, the venting slots are designed to increase air circulation and make the dirt and water are dispersed quickly
Full wave blades ensure optimum pad-to-rotor contact for maximum stopping force and feel
Stainless steel 420 (2Cr13) ensures durable braking power, HRC 36+- 2 heat treated to ensure warp resistance
Directly bolt on, no additional hardware necessary
Including (1) rotor
Outer diameter: 190mm
Inner diameter: 90mm
Thickness: 3.5mm
Hole size: 10.5mm
Bolt Pitch: 110mm
We marked the Min Thickness on the surface ,it means you should replace the brake disc rotor when the thickness with Minimum Thickness to ensure save ridding
