Product: Front CV Axles For John Deere Gator HPX 815E HPX 615E HPX 850D 4×2 4×4 HPX XUV

Product categories

Front CV Axles For John Deere Gator HPX 815E HPX 615E HPX 850D 4x2 4x4 HPX XUV

Front CV Axles For John Deere Gator HPX 815E HPX 615E HPX 850D 4x2 4x4 HPX XUV - Image 2

Front CV Axles For John Deere Gator HPX 815E HPX 615E HPX 850D 4x2 4x4 HPX XUV - Image 3

Front CV Axles For John Deere Gator HPX 815E HPX 615E HPX 850D 4x2 4x4 HPX XUV - Image 4

Front CV Axles For John Deere Gator HPX 815E HPX 615E HPX 850D 4x2 4x4 HPX XUV - Image 5

Front CV Axles For John Deere Gator HPX 815E HPX 615E HPX 850D 4×2 4×4 HPX XUV

SKU Z.15826 AM146259, AM138127, AM138630, AM140526, AM141845, AM142935, AM142360, AM146258, AM138126, AM138630, AM140525, AM141844, AM142934, AM142359 Category ATV CV Axles Tags axle, shaft

Premium Quality Replacement Part
Front Left Or Right CV Joint AxlesFor Can Am Models:Gator 4×2 4×4 HPX Diesel 4×4 Trail HPX Diesel Gator HPX815E HPX615E HPX850DGator XUV UTV 850DOrder Includes:
1x Front Left CV Joint Axle : AM146259, AM138127, AM138630, AM140526, AM141845, AM142935, AM142360
Length : 695.3mmSpline A Length : 49.8mmSpline A Boot Width : 86mmSpline A – 27 ToothSpline B Length : 40.8mm Spline B Boot Width : 78.4mmSpline B – 22 Tooth
1x Front Right CV Joint Axle : AM146258, AM138126, AM138630, AM140525, AM141844, AM142934, AM142359
Length : 638.1mm
Spline A Length : 49.6mm
Spline A Boot Width : 85.1mm
Spline A – 27 Tooth
Spline B Length : 43.2mm
Spline B Boot Width : 77.8mm
Spline B – 22 Tooth
**
