Product

Premium Quality Replacement Part
Intake Valve Kit for Yamaha 5AP-12111-01-00 3FA-12113-00-00 2HX-12119-00-00
For Yamaha Models:
Grizzly 125 YFM125G YFM125GH 2004-2013
Order Includes:
1 x Intake Valve: 5AP-12111-01-00
Intake Valve Length: 1.0″ | 26.0 mm
Intake Valve Diameter: 2.5″ | 64.4 mm
1 x Inner Valve Spring: 3FA-12113-00-00
Width: 0.79″ | 20.1 mm
Height: 1.20″ | 30.6 mm
Thickness: 0.10″ | 2.7 mm
1 x Valve Stem Seal: 2HX-12119-00-00
Length: 0.43″ | 11.0 mm
Width: 0.31″ | 8.0 mm
Inner Diameter: 0.19″ | 5.0 mm
Outer Diameter: 0.33″ | 8.4 mm
2 x Valve Cotter: 22F-12118-01-00
Width: 0.12 ” | 3.3 mm
Length: 0.29 ” | 7.5 mm
Height: 0.23 ” | 5.9 mm
**
