Product

Premium Quality Replacement Part
Intake Valve kit for Yamaha Kodiak 450 4×4 2003 2004 2005 2006 2018 2019-2022
For Yamaha Models:
Kodiak 450 4×4 2003-2006 2018-2022
Order Includes:
1 x Intake Valve: 5GH-12111-00-00
Intake Valve Length: 1.57″ | 40.0 mm
Intake Valve Diameter: 4.0″ | 103.0 mm
1 x Inner Valve Spring: 22U-12113-00-00
Width: 0.84″ | 21.4 mm
Height: 1.55″ | 39.6 mm
Thickness: 0.11″ | 2.9 mm
1 x Outer Valve Spring: 1UY-12114-01-00
Width: 1.22″ | 31.2 mm
Height: 1.71″ | 43.5 mm
Thickness: 0.16″ | 4.25 mm
1 x Valve Stem Seal: M01-12129-00-00
Length: 0.47″ | 12.0 mm
Width: 0.35″ | 9.0 mm
Inner Diameter: 0.18″ | 4.7 mm
Outer Diameter: 0.37″ | 9.4 mm
2 x Valve Cotter: 1J7-12118-00-00
Width: 0.16 ” | 4.2 mm
Length: 0.37 ” | 9.5 mm
Height: 0.27 ” | 7.0 mm
**
