Product: Intake Valve Kit for Yamaha Raptor 90 YFM90R 2009 2010 2011 2012 2013

Premium Quality Replacement Part
Intake Valve Kit for Yamaha Raptor 90 YFM90R 2009 2010 2011 2012 2013
For Yamaha Models:
Raptor 90 YFM90R 2009-2013
Order Includes:
1 x Intake Valve: 43D-12111-09-00 43D-E2111-00-00
Intake Valve Length: 0.82″ | 21.0 mm
Intake Valve Diameter: 2.44″ | 62.0 mm
1 x Outer Valve Spring: 43D-E2114-00-00
Width: 0.87″ | 22.1 mm
Height: 1.33″ | 33.8 mm
Thickness: 0.09″ | 2.5 mm
1 x Inner Valve Spring: 43D-E2113-00-00
Width: 0.63″ | 16.2 mm
Height: 1.0″ | 27.8 mm
Thickness: 0.06″ | 1.7 mm
1 x Valve Stem Seal: 43D-E2119-00-00
Length: 0.41″ | 10.5 mm
Width: 0.32″ | 8.2 mm
Inner Diameter: 0.18″ | 4.6 mm
Outer Diameter: 0.31″ | 7.9 mm
2 x Valve Cotter: 43D-E2118-00-00
Width: 0.14 ” | 3.6 mm
Length: 0.31 ” | 8.1 mm
Height: 0.20 ” | 5.3 mm
**
