Product: Primary Clutch Hardware Rebuild Kit for Polaris ATP 330 4×4 2004-2005

Premium Quality Replacement Part
Primary Clutch Hardware Rebuild Kit for Polaris ATP 330 4×4 2004-2005
For Polaris Models:
Polaris Sportsman 500 HO 2001-2012
ORDER INCLUDES:
3x Pivot Bolts | 7512266
3x Lock Nuts | 7541906
3x Steel Roller Bushings | 1321457
3x Steel Roller Pins | 5020422
6x Clutch Buttons | 5439254 | 5431936
6x Spider Washers | 5438247
2x Brass Spacer | 5210752 | 5242981
1x Bearing Cover | 3576510
1x Moveable Shaft Bushing | 3576504
Dimensions & Measurements :
ROLLER BUSHINGS | ID: 9.5mm | OD: 14.3mm | H: 9mm
ROLLER PINS | Diameter: 9.5mm | Length: 25mm
CLUTCH BUTTONS | 13.5mm x 6.5mm
BRASS SPACER 1 | ID: 34mm | OD:44.35mm | Thickness: .6mm
BRASS SPACER 2 | ID: 34mm | OD:44.35mm | Thickness: .7mm
Bearing Cover | ID: 29mm | OD: 33mm | H: 13mm
Moveable Shaft Bushing | ID: 38m | OD: 42mm | H: 12mm
