Product: Primary Drive Clutch Kit for Polaris Ranger 500 EFI 4X4 2011 – 2012 Rebuild Kit
Primary Drive Clutch Kit for Polaris Ranger 500 EFI 4X4 2011 – 2012 Rebuild Kit
Primary Drive Clutch Kit for Polaris Ranger 500 EFI 4X4 2011 – 2012 Rebuild Kit
Premium Quality Replacement Part
Primary Drive Clutch Rebuild Kit
For Polaris Models:
Ranger 500 Crew 4×4 2011-2012
Ranger 500 EFI 4×4 2011-2012
Ranger 500 Midsize 2013
Ranger 500 Midsize Crew 2013
Order Includes:
3x Clutch Weight (25-52G) | 5632409
1x Spring | 7043199
1x Needle Bearing (Non EBC) | 3514609
3x Roller 1321457 | 5020433
3x Roller Pin | 5020422
6x Roller Washer | 5438247 5430702 5430945
6x Button | 5439254 5431936
3x Bolt | 7512266
3x Nut | 7541906 3235320
2x Washer | 7556335
1x DU Bushing | 3514492
1x Bushing Cover | 3514684
1x Spacer Limiter | 5438823
1x Spacer 5633000 | 5632328
1x Bushing | 5430261
Dimensions & Measurements:
Needle Bearing
Item Height: 44.30 mm | 1.74″
Item Outer Diameter: 31.70 mm | 1.24
Clutch Spring
Item Length: 70 mm | 2.75″
Item Width: 50 mm | 1.9″
Item Thickness: 4.6 mm | 0.18″
Clutch Weight (25-52G)
Item Length: 57 mm | 2.24
Item Thickness: 9.7 mm | 0.38″
