Primary Drive Clutch Rebuild Kit for Polaris Sportsman Touring 570 EPS SP 19-24

SKU LHQPJ.07319 5020422, 5438247, 7512266, 7541906, 1321457 5020433, 5438247 5430702 5430945, 1323543 1323545 Category Tag
Spread the love
Share on facebook
Share on twitter
Share on linkedin
Share on whatsapp
Share on telegram
Share on tumblr
Share on pinterest

Premium Quality Replacement Part
Primary Drive Clutch Rebuild Kit
For Polaris Models:
Sportsman 450 HO EPS 2019-2022
Sportsman 450 HO EPS Utility 2020-2024
Sportsman 450 HO EPS 50S 2023-2024
Sportsman 570 EFI 2019-2024
Sportsman 570 EPS ZUG 2019-2024
Sportsman 570 EPS Utility 2021-2022
Sportsman Touring 570 EPS SP Tractor 2019-2023
Sportsman 570 X2 EU/ZUG 2019-2023
Sportsman 570 Premium 2020-2022
Sportsman 570 Euro 6X6 2019-2023
Order Includes:
3 x Clutch Weight : 5632409
PRING CLUTCH 35-2405632409 / CW110
3 x Roller : 1321457 5020433
Outer Diameter : 14.3 mm – 0.56″
Inner Diameter : 9.5 mm – 0.37″
Width : 9 mm – 0.35″
3 x Roller Pin: 5020422
Length : 25 mm – 0.98″
Outer Diameter : 9.5 mm – 0.37″
6 x Roller Washer : 5438247 5430702 5430945
Outer Diameter : 14.6 mm – 0.57″
Inner Diameter : 9.6 mm – 0.37″
Thickness : 1.5 mm – 0.059″
6 x Button : 5439254 5431936
Outer Diameter: 14 mm – 0.55″
Width : 6.5 mm – 0.25″
3 x Shoulder Bolt (Socket Head Cap Screw) : 7512266
Length : 63.8 mm – 2.51″M5x1.0
3 x Nut : 7541906 3235320
Inner Diameter : 4 mm – 0.15″
Height : 6.1 mm – 0.24″M5x1.0
