Product

Premium Quality Replacement Part
Rear Differential Seal & O Ring Kit For Honda Four Trax TRX300FW 4X4 1997-2000
For Honda Models:
Four Trax TRX300FW 4X4 1997-2000
Order Includes:
1 x O-Ring | 91302-001-020
1 x Oil Seal | 91251-HC5-005 91251-HA0-000 91251-HA0-003 91251-HA0-004 91251-HA0-013 91251-HA0-014
1 x Dust Seal | 91252-HM5-A11 91252-HC4-003
1 x Oil Seal | 91271-HC4-004
Dimensions & Measurements:
Oil Seal 1
Inner Diameter: 38mm | 1.49″
Outer Diameter: 64mm | 2.51″
Thickness: 14mm | 0.55″
Dust Seal
Inner Diameter: 42mm | 1.65″
Outer Diameter: 58mm | 1.65″
Thickness: 14.5mm | 0.57″
Oil Seal 2
Inner Diameter: 42mm | 1.65″
Outer Diameter: 51mm | 2″
Thickness: 6.5mm | 0.25″
Fit Differential Part Number: 41300-HC4-000 41300-HC5-970 41300-HM5-A10
**
