Product: Rear Differential Seal & O Ring Kit For Yamaha 93102-35009-00 / 93210-626A7-00

Premium Quality Replacement Part
Rear Differential Seal & O ring For Yamaha Models:GRIZZLY 660 2002-2008
GRIZZLY 660 Hunter Edition 2002 2005-2008
GRIZZLY 660 Autu 4×4 2004
GRIZZLY 660 SE 2005
Rhino 660 2004
Rhino 660 4WD Exploring Edition 2006-2007
Rhino 660 4WD Special Edition 2006-2007
Rhino 660 4WD Sport Edition 2007
Rhino 450 2006-2009
Rhino 450 Hunter 2007-2009
Rhino 450 Special Edition 2007-2008
Rhino 700 Fi 2008-2009
Rhino 700 Hunter 2011-2013
Rhino 700 Sport Edition 2011-2013
Order Includes:
1 x O Ring | 93211-54698-00 93211-51749-00
1 x O Ring | 93210-626A7-00 93210-63514-00
1 x O Ring | 93210-19123-00 93210-19800-00 93210-19809-00
2 x Oil Seal | 93102-65004-00 93102-65008-00
1 x Oil Seal | 93102-35009-00
Dimensions:
Oil Seal 1
Inner Diameter: 63mm | 2.48″
Outer Diameter: 90mm | 3.54″
Thickness: 9mm | 0.35″
Oil Seal 2
Inner Diameter: 33mm | 1.30″
Outer Diameter: 61mm | 2.40″
Thickness: 9mm | 0.35″
**
