Product: Spindle Housing For Toro 71185 71190 71191 71193 Lawn Tractor

Premium Quality Replacement Part
Spindle Housing
For Toro Models:
71185 (13-38 XL) – Toro Lawn Tractor (SN: 069000001 – 069999999) (1996)
71185 (13-38 XL) – Toro Lawn Tractor (SN: 079000001 – 079999999) (1997)
71185 (13-38 XL) – Toro Lawn Tractor (SN: 089000001 – 089999999) (1998)
71190 (13-38 XL) – Toro Lawn Tractor (SN: 079000001 – 079999999) (1997)
71190 (13-38 XL) – Toro Lawn Tractor (SN: 089000001 – 089999999) (1998)
71191 (13-38 HXL) – Toro Lawn Tractor (SN: 049000001 – 049999999) (1994)
71191 (13-38 HXL) – Toro Lawn Tractor (SN: 059000001 – 059100000) (1995)
71191 (13-38 HXL) – Toro Lawn Tractor (SN: 059010001 – 059999999) (1995)
71191 (13-38 HXL) – Toro Lawn Tractor (SN: 069000001 – 069999999) (1996)
71193 (14-38 HXL) – Toro Lawn Tractor (SN: 069000001 – 069999999) (1996)
71193 (14-38 HXL) – Toro Lawn Tractor (SN: 079000001 – 079999999) (1997)
Order Includes:
1 x Spindle Housing | 884510 1106866 1171192
Height: 146.4 mm | 5.76″
Inner Diameter: 11.6 mm | 0.46 ”
Outer Diameter: 161.8 mm | 6.37 ”
Mounting Hole Distance: 99.8 mm | 3.92 ”
Note: Deck Size 38 inch
**
