Product: Suzuki Quadsport Z400 / LTZ400 (2003-2008) & Kawasaki KFX400 (2005-2006) Front A-Arm

Premium Quality Replacement Part
Front Lower Right Left Control Arm & Bushing Kit
Compatible with Polaris Models:
General 1000 EPS 2016-2023
General 4 1000 EPS 2017-2022
RZR 4 900 EPS 2017-2018
RZR S 900 EPS 2017-2020
RZR Trail S 900 Sport 2021-2024
RZR S 1000 EPS 2017-2021
RZR S4 1000 EPS 2019-2021
RZR Trail S 1000 2021-2024
Order Includes:
1 x Control Arm Right: 1021417-458, 1021417-133, 1021417458, 1021417133
Length: 565.2 mm – 22.25 in
Height: 610mm – 24 in
Width: 66 mm – 2.59 in
Material: Hot Rolled Steel Seamless Tubing
1 x Control Arm Left: 1021416-458, 1021416-133, 1021416458, 1021416133
Length: 565.2 mm – 22.25 in
Height: 610 mm – 24 in
Width: 66 mm – 2.59 in
Material: Hot Rolled Steel Seamless Tubing
4 x Pivot Shaft: 5139966
Length: 51mm – 2 in
Inner Diameter: 10mm – 0 39 in
Outer Diameter: 16mm – 0 62 in
Material: Steel
8 x Bushing: 545223
Width: 15 5mm – 0 61 in
Inner Diameter: 16 5mm – 0 64 in
Outer Diameter: 26mm – 1 02 in
Material: Plastic
4 x Flange Washer: 7556153
Thickness: 2mm – 0 07 in
Inner Diameter: 10 6mm – 0 41 in
Outer Diameter: 19 8mm – 0 77 in
Material: Metal
8 x Sealed Pivot Cap: 1543611, 5139968
Width : 10.1mm – 0.39 in
Inner Diameter : 10.4mm – 0.41 in
Outer Diameter : 26.4mm – 1.04 in
Material: Metal
4 x Bolt: 7519043, 7518560
Length: 104mm – 4 09 in
Head Diameter: 15mm – 0 59 in
Threads Size: M10-1 25
Material: Iron
4 x Nut: 7547333
Width: 13mm – 0 51 in
Inner Diameter: 8 5mm – 0 33 in
Outer Diameter: 21 5mm – 0 84 in
Threads Size: M10-1 25
Material: Iron
